Air conditioning ignition sensor

This sensor is exclusively compatible with boats that are already equipped with Seanapps.
To equip your boat, discover the Seanapps Retrofit Pack.

PRICE: €149*

Ref : 225964

The air conditioning ignition sensor enables efficient tracking of your boat’s air conditioning system by detecting AC voltage fluctuations (110 or 220 volts).

Pay later: Pre-order online and pay with your installer upon delivery.

Delivery: directly to your authorized installer – Delivery fees not included.

*VAT rate not included + excluding delivery and installation costs.

It promptly alerts you to any electrical supply disruptions, ensuring your system’s continuous operation.

This sensor updates every 4 seconds for real-time accuracy. Its CR2450 3V battery has a two-year lifespan, minimizing maintenance. An LED indicator signals battery life for timely replacements.

Measuring 70x45x21mm, its robust black plastic design allows easy installation via adhesive or screws. Utilizing Bluetooth Low Energy 5.1, it offers a reliable 15 to 20 meters range, seamlessly connecting with the Seanapps system through QR code scanning.

Designed for easy battery access, this sensor is essential in maintaining a consistently comfortable environment aboard your boat.

  • Data: AC voltage presence
  • Data recurrence: 4 seconds
  • Battery type: CR2450 3V
  • Battery life: About 2 years
  • Battery data: 90% >2.4V / 50% >2.3V / 20%>2.1V /Alarm<=2.1V
  • Connector type: Windsta 2 pts type 890-812/011-000 (see adapter harness below)
  • Led: Flash at power ON / Flash every 60s if battery <2.5V
  • Protection against polarity reversals
  • Product dimensions: 70x45x21mm
  • Color: Black
  • Material: plastic (V0 material)
  • Fixing: gluing or x2 screws diameter 3mm
  • Protocol: Bluetooth Low Energy 5.1
  • Range: 15 to 20m in open field
  • Protection: tropicalized electronic card/Protection against water splashes
  • Seanapps pairing: QR code

It must be installed at the output of the circuit breaker of the line. The AC detector must be installed with the connector down in a technical compartment. It must be installed to be accessible to change the battery.

24-month commercial warranty
In case of a breakdown, the product is repaired free of charge by your dealer. If repair is not possible, the product is exchanged.

Dedicated customer service
Contact your certified Seanapps dealer for any questions regarding installation, configuration, or problem reporting.
